MULTI BOILER
Model: NSU6-60H Series GAS MODEL Natural Gas / LP Gas
SAN-EI CO., LTD.
Anyone can cook perfect noodles all the time.
If your restaurant serves noodle dishes, this is what you need.
Expect perfect results for cooking spaghetti, udon, ramen,
pho and all other types of pasta and noodles at rapid speed
every time.
The product functions and characteristics
Automatic cooking using digital timer
You can preset timer for the cooking. The basket rises itself after the timer times out and informs you. This
will prevent the noodle to be overcooked. When you busy with other tasks, you don't have to watch the
cooking and leave it alone. You can set timer per each basket so that you can cook mixture of thick, thin,
hard or soft noodle individually at the same time.
High temperature jet nozzle
The cooker sprays high temperature water so that it cooks noodles without tangle them. The jet nozzle
underneath of the basket sprays up hot water (100 Celsius) with steam through the noodles so that they are
cooked untangled. This cooking makes noodle delicious and strong consistently.
Built-in hot water tank
Built-in hot water tank (proprietary double suction type) makes it possible to continuously supply of about 75
Celsius add on water even during the winter time. Add on supply water is heated using exhaust heat for
cooking tank. Water level of the supply tank is maintained automatically so that supply tank always
maintains the same water level and temperature. You do not need external hot water supply.
(Water supply temperature may lower depending upon how much water you use.)
Energy conservation
For the energy conservation, this cooker equipped with two effective functions. The first one is to make the bottom of the cooking tank in
corrugated shape so that effective heat transfer area is doubled for the higher efficiency. The second one is our proprietary double heat
mechanism so that exhaust heat from the cooking tank burner is used to heat up supply hot water tank.
Made in JAPAN
Safety:
Equipped with automatic gas valve shutoff for safety when gas flames is extinguished or tank is empty.
Dimensions and Specifications ETL LISTED)
Model: NSU6-60HA ETL LISTED
*USA specification
*Only the natural gas and the LP gas
簡単操作で、誰でもプロの茹で上げが可能です。
パスタ・うどん・ラーメン・フォー・その他全ての
麺に対応することが出来ます。
よりスピーディ・正確に茹で上げることにより
効率的な調理オペレーションを可能にします。
Width x Depth x Height (in)
Weight (lb)
Gas Consumption
Power Consumption
Ignition
Safety Device
Basket Elevator
23.6in (600mm) x 29.5in (750mm) x 33.5in (850mm)
258Ib (117Kg)
Natural Gas 13A : 66569.3 BTU/h (19.5kW/h)
LP Gas : 66569.3 BTU/h (19.5kW/h)
AC120V 60Hz 91W
AC120V Continuous Sparks (Direct Ignition)
Flame Out : Thermal Couple / Empty Cooking : Thermostat(Limit Controller)
6 stations (3 x 2)
San-Ei (Noodle Boiler)
