W460xD460xH260~270mm
(with the cover opened: H750~760mm)
W225xD460xH255~265mm
(with the cover opened: H750~760mm)
W405xD470xH280~290mm
(with the cover opened: H755~765mm)
NAMBU IRONWARE
GYOZA HOT PLATES
Nambu ironware generally has certain thickness and weightiness that facilitate even heating and
good heat retention; that in turn ensures perfectly cooked food, cooked all through and crisp
surface when needed. Nambu ironware is very popular not only in Japan but also overseas for its
high quality and excellent designs (both traditional and innovative)
as high-end, heirloom cookware that will be cherished for generations.
U.S.
Boiling Steaming Grilling
2 Servings (10 Pieces)
4 Servings (20 Pieces)
LOW COST, YET LOADEDWITH CONVENIENT FEATURES AND FUNCTIONS
Convenient Plate
Divider
/
Water Dam with
Water Depth Indicator
• Even heating and high heat-retention of Nambu cast iron ensures superb taste and crispy skin
• Plate Divider lets you cook just one serving while retaining the appropriate water depth.
• Timer lets you adjust the cooking time to your preference.
• Easy to use; the thermostat keeps the cooking temperature at desired point.
• Electric heater for safe, clean and economical operation.
• No heat-generating open ame; lower ambient temperature; less air
conditioner use.
• Compact size, yet loaded with convenient features.
Removable Cover for
Easy Cleaning
Removable Cover for
Easy Cleaning
Removable Cover for
Easy Cleaning
1 Plate Divider
2 Plate Dividers
No Plate Divider
Cooking Steps:
1. Set the thermostat.
2. Wait until the temperature rises
to the set point.
3. Oil the plate; then place the
dumplings.
4. Add hot water up to the edges
of the dumplings.
5. Set the timer and wait until the
alarm goes o .
6. Drop some oil; the dumpling
are ready to serve.
(For detailed instructions, refer
to the instruction manual.)
u
Easy to Use
GS-1 STR-US
GS-2 STR-US
GS-1 LTR-US
Product
GS-1 STR-US
GS-2 STR-US
GS-1 LTR-US
Unit Dimensions
W225xD460xH255 (8.9”x18.1”x10.0”)
W460xD460xH260 (18.1”x18.1”x10.0”)
W405xD470xH280 (15.9”x18.5”x11.0”)
Plate Dimensions
W180xD340xH40mm (7.1”x13.4”x15.8x1.6”) W180xD340xH40mm (7.1”x13.4”x15.8x1.6”) x2 Plates W350xD365xH40mm (13.8”x14.4”x1.6”)
Unit Exterior
Stainless Steel
Plate Material
Nanbu Cast Iron
Cover Material
Molded Alminium w/Fluorocarbon Resin Coating
Legs
Adjustable 0-10mm (0-0.4”)
Power Input
(Voltage can be adjusted
to your requirement)
230V, 1.95Kw, 9.0Amps, Single Phase
230V, 3.9Kw, 18.0Amps, Single Phase
230V, 3.9Kw, 18.0Amps, Single Phase
Heating Speed
20⁰C to 200⁰C (7min30sec to 12min)
Temperature Range
190⁰C to 220⁰C (374 -428F)
Thermostat
Variable Liquid Expansion Type
Timer
0-15min with Alarm
Water Supply
Manual
Weight
17kg (37.4lb)
35kg (77lb)
35kg (77lb)
Subject to change without notice.
