J.C. uni-tec Products Catalog 2014

26 / 84

For further information, please contact your local dealer or visit our web site: 24
NEW JPC-3000 Series
Gas Powered Pressure Cooker
タイマー付き業務用圧力鍋
SANITATION
®
Timer Control
Preset cooking time (up to 60 mins) by
using the automated cooking timer or
disable timed cooking and use the
burner manually.
Flame High/Low Switch
Manually control the burner output by
using the high ame (Full power) or
the low ame (1/3 power).
Timer
Operated
Dual Thermostat Sensors
Two temperature sensors located on the base of
the burner provide:
1) Optimized Pressure Cooking: When base of
the cooking pot reaches 100°C (220F), burner
output is reduced by 2/3.
2) Burner Safety Shut-O : If base of cooking pot
reaches 130°C (266F), burner automatically
turns o to prevent over-heating.
JPC-3000は、高地や寒冷地などでも環境の影響を受け
ずに調理ができる圧力鍋/多目的調理鍋システムです。
Safety Cap、Color Coded Emergency Pressure Release
Valveなどの特許安全装置を備え、圧力鍋として安心して
使用できるだけでなく、Timer、Frame High/Low Switch
などの機能を使って高圧調理、常圧調理、豆、魚、肉のス
ロー・クック、出汁取り、その他、色々な用途に使用でき
る万能調理システムです。
Timer Dial: 右回りで60分までのタイマー設定。左回り
（Cont）ではタイマーなしの連続加熱。（2段階火力調整
可、フルまたは1/3）
Flame High/Low Switch: Highはフル出力、Lowは1/3
出力
Dual Thermostat Sensors: 鍋底の温度が100°C
（220F）になると火力を1/3に自動調整します。130°C
（266F）になると空焚き防止を行うセンサーが作動し
自動消火します。
ヒートスリーブと鍋はJPC-1000/3000のどちらにも使用
できる共通部品です。
JPC-1000/3000は安全でコストパフォーマンスの高い
画期的な新世代ガス圧力鍋です。
(Underside of Lid)
Patented Safety Cap
eliminates Clogging.
Patented
Safety Cap
3 Pressure Weights are Included
Light Wt 0 - 1,000m 0 - 3,281ft
Medium Wt 1,000 - 2,500m 3,281 - 8,202ft
Heavy Wt 2,500 - 3,000m 8,202 - 9,843ft
Chart for which weight to use at what altitude.
1) Burner activated - Pot temperature and pressure begin to build as
burner heats the pot.
2) Target temperature reached - burner lowers to simmer
3) Burner will remain on simmer until timer reaches 0, then
automatically shuts o . Temperature and pressure remain at the
same level until shut o by the timer.
Flame
Pressure
(Inside Cooker)
Time Temperature
1
2
3
Key Action Points
How the new burner operation a ects the JPC-3000 cooking:
The JPC units come with 3 di erent weights for
use with di erent types of cooking, such as high
altitude cooking (medium and heavy weights
are used) and cooking di erent types of rice,
such as brown rice (requires heavy weight).
圧力調整口の
詰りを防止。
JPC-3000 Pressure Cooker
